Home /Products/Hotel Partition Wall/Contemporary wood grain color sliding glass partition aluminum folding door for patio

Contemporary wood grain color sliding glass partition aluminum folding door for patio

10.0 Square Meters
MOQ
Contemporary wood grain color sliding glass partition aluminum folding door for patio
Features Gallery Product Description Request A Quote
Features
Specifications
Model Number: F80
Door Material: Glass
Warranty: 1 Year
Surface Finishing: Finished
Opening Method: Push And Pull
Door Type: Glass
After-sale Service: Online Technical Support, Onsite Installation
Main Material: Polymer
Project Solution Capability: Graphic Design, 3D Model Design, Total Solution For Projects
Application: Hotel, Residential House
Design Style: Contemporary
Color: Customized Colors
Material: Aluminum Alloy+Glass
Surface Treatment: Power Coating
Style: European-style Doors
Accessories: Lock+handles
Function: Soundproof Ect
Glass: Double Tempered Glass
Open Style: Folding
Position: Exterior
Type: SLIDING DOORS
Sliding Door Type: Folding Doors
Basic Infomation
Model Number: F80
Payment & Shipping Terms
Packaging Details: paper board or plywood case, up to customer's requirment.
Supply Ability: 2500 Square Meter/Square Meters per Month
Product Description
Product Description
Movable glass partition folding glazed wall aluminum frameless sliding glass doors
Product Name
Egood fordable door system F80
Material
anodized aluminum frames structure with insulation glass and floor and top track system
Function
smooth operation for opening and folding ,sound ,heat insolation and water proof
Package
strengthen paper carton and plywood case

  • Geranal specification

■80mm thickness panel ,minimum width 1500mm,Max height up to 3000mm. ■concealed hinge and,floor bolt, tracking system,simple appearance. ■single door leafe width:330mm to 1050m,max weights 120kg per leaf. ■clear anodized extruded aluminum frames,customized powder coated color are available. ■supported with floor and top track with roller ■Clear or Low E toughened safety insulating glass 6mm+12A+6mm=24mm thickness ■Wind pressure resistance :international grade 5 (30000ps) ■Air Permeability resistance:international grade 4(2.5m3/(m.h)) ■Water tightness resistance:international grade 3(300pa)
Product Advantages
Egood foldable door mechanical parts are all hidden in the profile cavity, with uniform pressure and smoother opening; it solves the problem that most of the ordinary foldign door may not smooth due to the exposed mechanical parts and the ash in the track may damages the pulley. Ou hinge is installed in the profile cavity with better stress, simple appearance and Enhance

Imported handlel lock and Top level roller&transmission system hardwres, the roller made by wear-resistant and quiet material ,ensure sliding and safety performance; brands we work with such as Italian Savio, ROTO, TRUTH or other equal quality brand.

This system adopts double- sealing design, which applies the principle of equal pressure and has excellent performance of water and air tightness.



Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.






1.
There is anti-collision design so The door panel shall be able to fold evenly and not Cause impact sound while folding,and it avoiding clamps people’s hand when opening and closing the folding door, ensuring smooth and safe operation.






2.
The ladder style and bottom profile goes with stainless steel track and roller system , nexcellent loading capacity ,long ware resistance,and outstanding waterproof performance.after install the door,there is still 3-5mm talerace for adjucting if the panels leveing is no match or panel sink happen;the superior stainelss floor bolot system, the 14mmθ Stainless steel floot bot  make   the the excellent theftproof and wind-resistant capability .





3.
The folding door adopt strength collision profile angle as corner joint ,it is high-precisionand reliable in quality, and easy
and flexible to replace glasses or maintenance.its applicable to high-end product series.






4.
Each door set carries double glazed unites incorporating clear or Low E toughened safety insulating glass 6+12A+6 or 5+12A+5 as standard manufactured and tested in accordance with European and American standards.





5.
Based on the integration of waterpoof test and data partial experience ,we made special design to the outer frame waterproof treatment,The ladder style bottom profile,The Indoor frame is high and outdoor fame is low,the workmanship is harder and more materials is requested but perfect waterproofing. also there is a drain outlet design at the bottom of the profile



Egood Foladble wall system confirguaion option

Our Foldable door system are availbe for in a range of 14 different configurations as shown below ,the quantity of the doors leave is depend on sactua site dimension ,if there is any other configuration request ,please contact with us:
Project Cases
Standard Colors
Our foldable doors are available in an array of read-made standard powder coat colors and finishes.Ral color or woodgrain color can be also supplied as be customized.
Related Products
Packing&Shipping
Paper board or plywood case, up to customer's requirement.
Company Introduction
Guangdong Egood Partition Products Co., Ltd. locates in Foshan China, is a professional manufacturer engaged in development, sales, production and after-sales service of movable partition wall and glass partition system.

The products are extensively applied to hotel meeting room, restaurant,banquet hall, convention center or exhibition center which providing convenient and effective space management solution. Highest panel can be up to 20 meters, max sound insulation can reach 56 db.
We own two modern production bases which occupies 10,000 squaremeters, equipped with all advanced production machines and high-efficiency operation tools. We research all products independently, with all of its intellectual property
and manufacturing technology.

we have been certified SGS product certification, ASTM acoustical test,fire test and ISO9001 quality system certification.

After years development, we have developed 3 popular brands “Egood”and “AE” and “Jinlishi”. Among them, the Germany “AE” brand has met the same quality level as international brand line, with satisfactory service and product, we have
exported over 100 countries among which 180 five star hotels completed, and enjoyed good reputation in the past years.
